74 Chapter 6: Working with system board components
1
2
Battery
Retaining
Clip
Replacing the system battery
To replace the battery, follow these steps:
1. Place the blade of a small, flat-blade screwdriver
under the edge of the retaining clip.
2. Turn the screwdriver one quarter turn, raising the
clip while pressing down on the old battery to
remove it.
3. Raise the retaining clip, and insert a new 3-volt
(CR2032) lithium battery in its place.
Note:
Make sure the positive side of the battery (the
side with a + symbol printed on it) is facing up
when you insert the battery into the socket.
