166 Appendix C: Modem information

+FTH=<m> Transmits high-level data link control (HDLC) data with <m> carrier:

<m>=3 Transmits using V.21 Channel 2 modulation at 300 bits per second (bps)

<m>=24 Transmits using V.27ter modulation at 2400 bps

<m>=48 Transmits using V.27ter modulation at 4800 bps

<m>=72 Transmits using V.29 modulation at 7200 bps

<m>=96 Transmits using V.29 modulation at 9600 bps

<m>=73 Transmits using V.17 modulation at 7200 bps

<m>=74 Transmits using V.17 (short train) modulation at 7200 bps

<m>=97 Transmits using V.17 modulation at 9600 bps

<m>=98 Transmits using V.17 (short train) modulation at 9600 bps

<m>=121 Transmits using V.17 modulation at 12,000 bps

<m>=122 Transmits using V.17 (short train) modulation at 12,000 bps

<m>=145 Transmits using V.17 modulation at 14,400 bps

<m>=146 Transmits using V.17 (short train) modulation at 14,400 bps

+FRH=<m> Receives high-level data link control (HDLC) data with <m> carrier:

<m>=3 Receives using V.21 Channel 2 modulation at 300 bits per second (bps)

<m>=24 Receives using V.27ter modulation at 2400 bps

<m>=48 Receives using V.27ter modulation at 4800 bps

<m>=72 Receives using V.29 modulation at 7200 bps

<m>=96 Receives using V.29 modulation at 9600 bps

<m>=73 Receives using V.17 modulation at 7200 bps

<m>=74 Receives using V.17 (short train) modulation at 7200 bps

<m>=97 Receives using V.17 modulation at 9600 bps

<m>=98 Receives using V.17 (short train) modulation at 9600 bps

<m>=121 Receives using V.17 modulation at 12,000 bps

<m>=122 Receives using V.17 (short train) modulation at 12,000 bps

<m>=145 Receives using V.17 modulation at 14,400 bps

<m>=146 Receives using V.17 (short train) modulation at 14,400 bps

Table 14: Common modem commands

Code/Command Function
