Table 12. Parts listing for DS3500 (continued)
Index Description
CRU part
number
(Tier 1)
CRU part
number
(Tier 2)
FRU
part
number
7 Power supply, ac 69Y0201
8 6 GB SAS 2–port host port adapter 69Y2840
8 8 GB FC 4–port host port adapter 69Y2841
8 1 GB iSCSI 4–port host port adapter 69Y2842
9 Filler panel, host port adapter 39R6543
10 Controller with 1 GB DIMM, no host port
expansion adapter
68Y8481
DIMM, 2 GB cache memory 69Y2843
Backup battery module 69Y2844
IBM 1-meter mini-SAS cable 39R6530
IBM 3-meter mini-SAS cable 39R6532
Service cable 13N1932
Power cord, rack jumper, 2.8-meter 39M5377
Miscellaneous rack mounting hardware kit 39R6551
Environmental service module 69Y0189
1 GB shortwave SFP transceiver 69Y2899
Power cords
For your safety, IBM provides a power cord with a grounded attachment plug to use
with this IBM product. To avoid electrical shock, always use the power cord and
plug with a properly grounded receptacle.
IBM power cords used in the United States and Canada are listed by Underwriter's
Laboratories (UL) and certified by the Canadian Standards Association (CSA).
For units intended to be operated at 115 volts: Use a UL-listed and CSA-certified
cord set consisting of a minimum 18 AWG, Type SVT or SJT, three-conductor cord,
a maximum of 15 feet in length and a parallel blade, grounding-type attachment
plug rated 15 amperes, 125 volts.
For units intended to be operated at 230 volts (U.S. use): Use a UL-listed and
CSA-certified cord set consisting of a minimum 18 AWG, Type SVT or SJT,
three-conductor cord, a maximum of 15 feet in length and a tandem blade,
grounding-type attachment plug rated 15 amperes, 250 volts.
For units intended to be operated at 230 volts (outside the U.S.): Use a cord set
with a grounding-type attachment plug. The cord set should have the appropriate
safety approvals for the country in which the equipment will be installed.
IBM power cords for a specific country or region are usually available only in that
country or region.
138 System Storage DS3500 and EXP3500: Installation, User’s, and Maintenance Guide
