Physical specifications for Model S54
This section gives physical specifications (such as height, width, depth, and
weight) for Model S54 of the TS3500 Tape Library.
Table 36. Physical characteristics of the TS3500 Tape Library, Model S54
Physical Characteristic Measurement
Height of S54 frame (on casters) 1 800 mm (70.9 in.)
Height of S54 frame with shuttle station
3
2 275 mm (89.57 in.)
Width of frame with covers 782 mm (30.8 in.)
Width of frame without covers
1
725 mm (28.5 in.)
Depth of S54 frame (including front and rear doors) 1 212 mm (47.72 in.)
Weight of base frame with 0 cartridges 290.3 kg (640 lb)
Weight of base frame with shuttle station and 0
cartridges
3
306.5 kg (675.72 lb)
Weight of frame with maximum cartridges (1 320
Ultrium tape cartridges)
2
562.5 kg (1 240 lb)
Weight of frame with shuttle station and
maximum (1 320) Ultrium tape cartridges
3
578.7 kg (1 275.82 lb)
Notes:
1. Frame width only. Additional interframe spacing of 30 mm (1.2 in.) is required.
2. The weight with cartridges assumes a cartridge weight of .206 kg (.454 lb) for a standard LTO Ultrium tape
cartridge. The actual weight of the library varies, depending on the configuration and cartridge capacity.
3. One shuttle station can optionally be mounted on a Model S54 frame in a TS3500 Tape Library shuttle complex.
Chapter 2. Physical planning specifications 99
