Power requirements for frames
This topic describes the power requirements for frames in the TS3500 Tape Library.
Table 43 lists the electrical characteristics for the TS3500 Tape Library frame
models.
Table 43. Electrical characteristics of the IBM System Storage TS3500 Tape Library frame
models
Electrical characteristic
Rating
2
Models L23, D23, L53, D53
Models L22, D22, L32, D32,
L52, D52
Nameplate electrical limits
1
200–240 V ac, 8.0 A, 50–60
Hz, 1.6 kVA, single phase
100–127 V ac, 12.0 A, 50–60
Hz, 1.2 kVA, single phase
200–240 V ac, 8.0 A, 50–60
Hz, 1.6 kVA, single phase
Inrush current 150 A @ 200–240 V ac (peak
for 1/2 cycle)
100 A @ 120 V ac, 200 A @
240 V ac (peak for 1/2 cycle)
Leakage current 1 mA 8 mA maximum with 12
drive power supplies
installed
Notes:
1. Maximum certified electrical limits for a single frame. Nameplate limits should not be
used to calculate product power or cooling requirements.
2. Models HA1, SC1, S24, and S54 do not connect to external ac power.
Table 44 lists the power consumption of the TS3500 Tape Library models, power
consuming features, and drive canisters.
Table 44. Power consumption of TS3500 Tape Library frame models, power consuming
features, and drive canisters
Models
Power consumption (Watts)
Off
7
Idle
Max. continuous (not
peak)
L32, L22, L52 7 200 260
D32, D22, D52
2
7 200 200
L23, L53
1
13 142 202
D23, D53
1,2
13 103 103
S24, S54
3
055
HA1
4
02485
SC1 (FC 1850 and
1851)
8
01120
Feature Codes
FC 1503 and 1504
(Drive mounting kit
for xx2 models)
5
01520
FC 1513, 1514, and
1515
(Drive mounting kit
for xx3 models)
5
047
120 IBM System Storage TS3500 Tape Library with ALMS: Introduction and Planning Guide
||||
||||
