Capacity of Model L52, D52, L53, D53, and S54 Frames
This section gives the type of eligible Capacity On Demand feature and quantity of
drives, I/O slots, and storage slots for Model L52, D52, L53, D53, and S54 frames.
Table 68. Quantity of storage slots in Model L52, D52, L53, D53, and S54 frames. The quantity depends on the type
of Capacity On Demand Expansion feature installed, whether the upper and lower I/O stations are used, and the
quantity of drives in a frame.
Type of Frame
Type of Capacity On
Demand (CoD)
Feature Quantity of Drives Quantity of I/O Slots
Quantity of Storage
Slots
L52, L53 No CoD (Entry) 0 to 12 16 64
L52, L53 Intermediate CoD 0 to 12 16 129
L52, L53 Full CoD 0 to 4
16 287
32 245
L52, L53 Full CoD 5 to 8
16 273
32 231
L52, L53 Full CoD 9 to 12
16 261
32 219
D52, D53
1
N/A
2
0
0 440
64
3
264
D52, D53
1
N/A 1to4
0 422
64
3
246
D52, D53
1
N/A 5to8
0 408
64
3
232
D52, D53
1
N/A 9to12
0 396
64
3
220
S54 No CoD (Base) 0 0 660
S54 HD CoD (Maximum) 0 0 1320
Notes:
1. If the L frame is not an L32, L52, or L53, then the first D frame of a mixed media library will have one less
storage slot to accommodate a diagnostic cartridge.
2. N/A = not applicable.
3. The 64 Additional I/O Slots feature (FC 1655) is only available on frame model D53.
Chapter 7. Frame capacity 213
