Routing Fibre Channel cables through the top of a frame
This section describes how to route Fibre Channel cables from servers through the
top of a frame in the TS3500 Tape Library.
As an alternative to routing Fibre Channel cables from servers to the bulkhead at
the bottom rear of the TS3500 Tape Library, you can route the cables through the
top of the library frame (see 1 in Figure 22 on page 109).
Y
Z
X
C
418
16.46
B
2 035
80.12
A
762 - 2743.2
30 - 108
D
2 375
93.5
Figure 21. Shuttle complex dimensions and clearances
