(2X) 24.4
(1.0)
(2X) 699.2
(27.5)
(2X) 1392.9
(54.8)
(2X) 1265.1
(49.8)
(2X) 807.4
(31.8)
(2X) 357.8
(14.1)
(2X) 258.2
(10.2)
(2X) 130.5
(5.1)
(2X) 57.5
(2.3)
(2X) 99.9
(3.9)
(2X) 648.2
(25.5)
(2X) 690.7
(27.2)
Front
Rear
762
(30)
460
(18.11)
762
(30)
762
(30)
762
(30)
83
(3.3)
Leveling pad
Caster
Power cord exit
Cable exit area
Operator side
Move restraints
a69i0293
B
A
Figure 20. Size of operator and service clearances for the IBM System Storage TS3500 Tape Library, Models L32 and
D32. The top measurements are in millimeters; the bottom measurements are in inches. The service clearance area
(and operator clearance area at the front of both frames) is denoted by dotted lines.
106 IBM System Storage TS3500 Tape Library with ALMS: Introduction and Planning Guide
