Table 12. Parts listing, Types 7143, 7145, 7146, and 7191 (continued)
Index Description
CRU part
number (Tier
1)
CRU part
number (Tier
2)
FRU part
number
15 Hard disk drive, SATA MultiBurner (models H1x H2x) 44W3256
15 Hard disk drive, 600 GB 10K, 2.5-inch SAS (models H1x,
H2x, H3x)
49Y2004
15 Hard disk drive, 300 GB 10K, 2.5-inch SAS (optional) 42D0638
15 Hard disk drive, 73 GB 15K, 2.5-inch SAS (optional) 42D0673
15 Hard disk drive, 146 GB 15K, 2.5-inch SAS (optional) 42D0678
15 Hard disk drive, 146 GB (optional) 42D0633
16 Hard disk drive filler (see Filler Kit)
17 Operator information panel (all models) 46M0059
18 200 Gb SATA 1.8 inch MLC SSD (models 4Fx, 5Gx) 40K6897
18 50 Gb SATA SSD (optional) 43W7717
19 1.8 inch SSD backplane and cage (models 4Fx, 5Dx, 5Gx,
D1x, D2x, D3x, D4x)
59Y6222
20 1.8 inch SSD filler blank (model 5Dx) 49Y4936
21 Front bezel (all models) 59Y4818
22 DVD SAP HANA v 1.5.53-5 46W8273
22 DVD SAP HANA v 1.6.60-6 00AK712
22 DVD/CD-RW SATA drive (some models only) 44W3254
22 DVD/CD multi-burner SATA drive (some models only) 44W3256
22 DVD UltraSlim Enhanced SATA drive (optional) 44W3254
23 Battery tray (see Miscellaneous hardware parts kit)
24 Front fans (120 mm) (all models) 59Y4813
25 Memory card cage (included in chassis assembly)
26 Middle fans (dual 60 mm) (all models) 59Y4812
27 Memory card filler (see Filler Kit)
28 CPU card 47C2444
28 Memory card 47C2450
28 Memory card (Types 7143 and 7191) 69Y1742
28 Memory card (Types 7145 and 7146) 46M0001
28 Memory board 47C2433
29 DIMM, 1 GB (optional) 44T1490
29 DIMM, 2 GB (all) 44T1491
29 DIMM, 2 GB 49Y1423
29 DIMM, 2 GB (all models) 49Y1443
29 DIMM, 4 GB (models 1Rx, 2Rx, 2Sx, 3Rx, 4Dx, 4Fx, 4Rx,
4Sx, 5Dx, 5Gx, 5Rx, 5Sx)
46C7452
29 DIMM, 8 GB (optional) 46C7488
29 DIMM, 16 GB (optional) 46C7489
29 DIMM, 8 GB (optional) 49Y1381
84 IBM System x3850 X5 and x3950 X5 Types 7145, 7146, 7143, and 7191: Problem Determination and Service Guide
