Replaceable server components
This topic provides a parts listing for all removable server components.
Replaceable components are of four types:
v Consumable part: Purchase and replacement of consumable parts (components,
such as batteries and printer cartridges, that have depletable life) is your
responsibility. If IBM acquires or installs a consumable part at your request, you
will be charged for the service.
v Tier 1 customer replaceable unit (CRU): Replacement of Tier 1 CRUs is your
responsibility. If IBM installs a Tier 1 CRU at your request with no service
agreement, you will be charged for the installation.
v Tier 2 customer replaceable unit: You may install a Tier 2 CRU yourself or
request IBM to install it, at no additional charge, under the type of warranty
service that is designated for your server.
v Field replaceable unit (FRU): FRUs must be installed only by trained service
technicians.
Table 12. Parts listing, Types 7143, 7145, 7146, and 7191
Index Description
CRU part
number (Tier
1)
CRU part
number (Tier
2)
FRU part
number
1 Top cover (all models) 59Y4815
2 QPI wrap card filler (see Filler Kit)
3 QPI wrap card (models D1x, D3x, D4x, D2x, H2x, HBx) 00D0561
4 Power supply filler (see Filler Kit)
5 Power supply, 1975 Watt 69Y5945
Power supply, 675 Watt 69Y5943
6 Emulex 10GbE Custom Adapter for IBM System x (all
models)
49Y4202
7 I/O-board shuttle (Types 7143 and 7191) 88Y5422
7 I/O-board shuttle (Types 7145 and 7146) 69Y1851
7a PCI latch kit for the I/O-board shuttle assembly 59Y4983
8 Chassis assembly (all models) 59Y4814
9 Hard disk drive backplane filler (see Filler Kit)
10 Hard disk drive backplane (all models except 4Fx, 5Dx,
5Gx, ARx)
43V7070
11 Hard disk drive backplane carrier (see Miscellaneous
hardware parts kit)
12 Hard disk drive backplane power cables and carrier (see
Cabling Kit)
13 RAID card carrier (see Miscellaneous hardware parts kit)
14 ServeRAID-BR10i SAS/SATA Controller (all 7145/7191
models except 4Fx, 5Dx, 5Gx)
44E8690
14 ServeRAID-M5015 SAS/SATA Controller (models D4x,
H1x, H2x, H3x)
46M0851
15 Hard disk drive, 200 GB SSD (models 4Fx, 5Gx, D1x, D2x) 40K6897
15 Hard disk drive, 200 GB SSD (models D3x, D4x) 49Y6120
Chapter 4. Parts listing, Types 7145, 7146, 7143, and 7191 83
