Front view
Operator
information
panel
USB connectors
DVD-eject
button
Hard disk drive
activity LED
Electrostatic-discharge connector
DVD drive
activity LED
Hard disk drive
status LED
Scalability
LED
Removing and replacing server components
This topic provides information about the four types of replaceable server
components.
Replaceable components are of four types:
v Consumable part: Purchase and replacement of consumable parts (components,
such as batteries and printer cartridges, that have depletable life) is your
responsibility. If IBM acquires or installs a consumable part at your request, you
will be charged for the service.
v Tier 1 customer replaceable unit (CRU): Replacement of Tier 1 CRUs is your
responsibility. If IBM installs a Tier 1 CRU at your request, you will be charged
for the installation.
v Tier 2 customer replaceable unit: You may install a Tier 2 CRU yourself or
request IBM to install it, at no additional charge, under the type of warranty
service that is designated for your server.
v Field replaceable unit (FRU): FRUs must be installed only by trained service
technicians.
Removing and replacing consumable parts and Tier 1 CRUs
This topic provides general information about removing and replacing consumable
parts and Tier 1 CRUs.
Replacement of Tier 1 CRUs is your responsibility. If IBM installs a Tier 1 CRU at
your request, you will be charged for the installation.
The illustrations in this document might differ slightly from your hardware.
Chapter 5. Removing and replacing components 105
To Next Page
