Removing an adapter
This topic provides instructions for how to remove a PCI Express adapter.
About this task
To remove a PCI Express adapter, complete the following steps.
Adapter
Adapter
retention
latch
Pin
Pin hole
Expansion
slot cover
Procedure
1. Read the safety information that begins with “Safety” on page v and
“Installation guidelines” on page 97.
2. Turn off the server and peripheral devices, and disconnect the power cords and
all external cables as necessary to remove the adapter.
110 IBM System x3850 X5 and x3950 X5 Types 7145, 7146, 7143, and 7191: Problem Determination and Service Guide
