Slot 7
error
LED
I/O
board
error
LED
Slot 6
error
LED
Slot 5
error
LED
Slot 4
error
LED
Slot 3
error
LED
Slot 2
error
LED
Slot 1
error
LED
Power fault LED
“I/O-board LEDs” on page 26 describes the function of each non-light path
diagnostics status LED.
Table 8. I/O-board non-light-path-diagnostics status LEDs
LED Description
Slot1-7errorLEDs When one of these LEDs is lit, it indicates that an error has occurred in the
associated I/O slot.
I/O board error LED When this LED is lit, it indicates that an error has occurred on the I/O
board.
Note: You must look at the server at an angle from the front to see this
LED.
I/O-board jumpers
This topic provides an illustration that shows the jumpers on the I/O board.
The following illustration shows the jumpers on the I/O board.
Chapter 2. Introduction 27
