The following illustration of the microprocessor board shows the locations of the
microprocessor sockets.
Microprocessor 1
Microprocessor 2
Microprocessor 3
Microprocessor 4
Removing a microprocessor and heat sink:
This topic provides instructions for how to remove a microprocessor and heat sink.
Chapter 5. Removing and replacing components 161
