41
CHAPTER 7 SPECIFICAITONS
1. VIDEO
Input Level
1.0 Vp-p±10% Composite, 75 Balanced
NTSC 120fps
Display Speed
PAL 100fps
NTSC 720(H) X 480(V)
Display Resolution
PAL 704(H) X 576(V)
Monitor Output
2Vp-p Composite, 75 Balanced
2. RECORDING
Compression Method H.264
Recording Speed Refer to table 7-1
NTSC 720 X 480, 720 X 240, 360 X 240
Recording Resolution
PAL 704 X 576, 704 X 288, 352 X 288
Quality
Independent for
each channel
Below Basic/ Basic/ Normal/ High/ Highest
Schedule Setup by “minute” as unit
Mode Manual / Event (Motion) / Schedule
Method
By resolution, fps and quality
Setup fps and quality separately for normal and
event recording
3. SATA DEVICE
Capacity Internal Storage 1 HDD
Type
SATA / SATAⅡ compatible
4. CONNECTIONS
Video Input 4 ports
Video Output BNC 1 port, VGA 1 port (max.1920 X 1080)
Audio Input RCA 1 CH
Audio Output RCA 1 CH
USB 2.0 USB memory stick, USB Touch Panel
USB 1.1 USB Mouse
Remote Remote control
External I/O N/A
Ethernet 1 RJ45 connector, 10/100 Mbps
5. ELECTRICAL
Power Source DC 12V / 3A
6. ENVIRONMENTAL
Operation Temperature
5℃ ~ + 40℃
Humidity Less than 90%
7. PHYSICAL
Dimension 300(W) x 175(D) x 46(H) mm
Weight
1.3 KG（not including HD）
