iCatch 411L - Hard Disk Installation Guide

6
1-2 Hard Disk Installation
Step 1: Take off the three screws from the bottom of the DVR as indicated in red circles in
the picture below.
Step 2: Open the cover follow the way the arrows indicate.
Step 3: Fix the HDD to rack mount and connect SATA and the power cable as indi
cated.
