Icom i2730A User Manual

59
8
OTHER FUNCTIONS
New2001 New2001
New2001
Tone Squelch function (Continued) ■
D Setting the DTCS code
Push [MENU q ]C.
 •EnterstheMENUmode.
w Rotate [DIAL]S to select “CODE” (DTCS Code).
Push [ e ï]D.
 •Goestothenexttreelevel.
Rotate [DIAL] r S to select a desired tone code.
Selectable options: 023 to 754
Push [ t ï]D.
 •Setstheselectedoption,andgoesbacktotheprevioustreelevel.
Push [MAIN BAND] y S.
 •ExitstheMENUmode.
D Setting the DTCS polarity
Push [MENU q ]C.
 •EnterstheMENUmode.
w Rotate [DIAL]S to select “DTCS-P” (DTCS Polarity).
Push [ e ï]D.
 •Goestothenexttreelevel.
Rotate [DIAL] r S to select a desired DTCS polarity.
Selectable options:
 •BOTHN:TXandRXpolarityareNormal.
 •TN-RR: TXpolarityisNormal,RXpolarityisReverse.
 •TR-RN: TXpolarityisReverse,RXpolarityisNormal.
 •BOTHR:TXandRXpolarityareReverse.
Push [ t ï]D.
 •Setstheselectedoption,andgoesbacktotheprevioustreelevel.
Push [MAIN BAND] y S.
 •ExitstheMENUmode.
S
ide
S
ide
D
isplay
C
enter
The C, S, or D in the
instructions indicate the
area of the controller.
C: Center
S: Side
D: Display
