Icom IC-7100 User Manual

14
VOICE MEMORY FUNCTION
14-9
Previous view
In the default settings, the transceiver records audio
only while receiving signals (the squelch is open).
If you want to continue recording even if no signal is
received, do the following steps.
Push q
SET
(C) to enter the Set mode.
Touch the “RX REC Condition” item of the “Voice w
Memo” Set mode.
( Voice Memo > QSO Recorder > Recorder Set >
RX REC Condition)
• If the specifi ed item is not displayed, touch [∫] or [√](D)
one or more times to select the page.
Touch “Always” to continuously record even if no sig- e
nal is received.
• Always: Recording continues, even if no signals
are received.
• Squelch Auto: The transceiver records audio only while
receiving signals (the squelch opens).
Push r
SET
(C) to exit the Set mode.
Continue to record even if no signals are received
SET
Touch
“RX REC Condition.”
Touch
“Voice Memo.”
Touch
“QSO Recorder.”
(Example)
Touch “Always.”
The L, R, C or D in the
instructions indicate the
part of the controller.
L: Left side
R: Right side
C: Center bottom
D: Display (Touch panel)
L
eft
R
ight
C
enter
D
isplay
Touch
“Recorder Set.”

Icom IC-7100 Specifications

General

Supply	13.8 V DC ±15%
Voltage	13.8 V DC
Operating Temperature	-10°C to +60°C
Frequency Coverage	0.030-199.999 MHz, 400-470 MHz
Modes	SSB, CW, AM, FM, DV
Output Power	HF/50MHz: 100W, 144MHz: 50W, 430MHz: 35W
Receiver Type	Superheterodyne
Antenna Connector	SO-239 (HF/50MHz/144MHz), N-type (430MHz)
Weight	Main unit: 2.3 kg
Type	Base/Mobile
Frequency Range TX	1.8–54 MHz, 144–148 MHz, 430–450 MHz
Frequency Range RX	0.030–199.999 MHz, 400–470 MHz
Memories	505
Current Consumption	TX: 22 A, RX: 1.2 A
