Icom IC-7100 User Manual

iii
SUPPLIED ACCESSORIES
The following accessories are supplied with the transceiver.
q Hand microphone ............................................... 1
w Control cable ....................................................... 1
e Ferrite bead .......................................................... 1
r 3.5 (d) mm plug .................................................... 1
t ACC cable ............................................................ 1
y DC power cable* (OPC-1457) ............................ 1
or (OPC-1457R) ......................... 1
u Spare fuse (ATC 5 A) ......................................... 1
i USB cable ............................................................ 1
o CD ........................................................................ 1
!0 Spare fuse (ATC 30 A) ....................................... 2
* Depending on the version.
* Not supplied, or the shape is different, depending on the trans-
ceiver version.
qw e
r
t
io !0
yu

Icom IC-7100 Specifications

General

Supply	13.8 V DC ±15%
Voltage	13.8 V DC
Operating Temperature	-10°C to +60°C
Frequency Coverage	0.030-199.999 MHz, 400-470 MHz
Modes	SSB, CW, AM, FM, DV
Output Power	HF/50MHz: 100W, 144MHz: 50W, 430MHz: 35W
Receiver Type	Superheterodyne
Antenna Connector	SO-239 (HF/50MHz/144MHz), N-type (430MHz)
Weight	Main unit: 2.3 kg
Type	Base/Mobile
Frequency Range TX	1.8–54 MHz, 144–148 MHz, 430–450 MHz
Frequency Range RX	0.030–199.999 MHz, 400–470 MHz
Memories	505
Current Consumption	TX: 22 A, RX: 1.2 A
