Entering text data is done by pressing keys multiple times to show the character required. The display will
change as the key is pressed.
For example, using the character key map shown, to enter the name
John , you would press the [5] key once for
J , move the cursor one location to the right using the [] key, press the [6] key seven times for o , and repeat the
procedure for the other characters in the text entry.
For more productive management of a Protege System ask your security professional about the
Protege System Management Suite.

2.6 Option Entry
The Protege LCD keypad uses option programming entry when configuring a yes or no option setting. Option
screens are shown with eight characters enclosed in '[' brackets.

Numerical Option Key Entry
If an option is enabled the corresponding number will be shown or when disabled a '*' will be shown in place of
the option.
UN00010 Misc
[*****6*8]
In the example shown option 6 and 8 are enabled. The example shows the miscellaneous options group when
programming a user.

Detailed Text - Option Key Entry
In many cases options are not known by the numerical number alone. In this case the Protege System provides a
text based entry system for options allowing the complete system to be programmed without the need for a
reference manual.
UN00010 Misc
[*****6*8]
In any option entry screen press the [STAY] key. The display will change and now show you the text description
of the first option in the option entry location that you are programming.
1. Show greeting
at user logon: N
In any option entry screen press the [STAY] key. The display will change and now show you the text description
of the first option in the option entry location. Press the [1] key to toggle the option state ('Y' or 'N'). Use the []
and [] keys to scroll the options within the option entry. When the required options have been set press the
[STAY] key and you will be returned to the option entry screen where the changes you have made will be
applied. Press the [ENTER] key to save your changes and proceed to the next programming screen.

