48 PRT-KLCD Protege Alphanumeric LCD Keypad User Manual | April 2011
9 Door Groups
Door groups are used to define what doors a user will be able to access and/or control. A door group is assigned
to an access level (see page 38) to restrict the ability for a user to gain en
try or exit to certain doors. The Protege
system supports up to 250 door groups.
9.1 All Doors Group
The All Doors group is a special door group that allows access to all doors within the system. The All Doors
group is assigned to the master access level by default.
Changing the All Doors group is not recommended as it will restrict access to the doors by the Master
Access Level.
9.2 Programming Door Groups
Door groups should be programmed so that they are used for a group of users, for example administration,
warehouse and management where the groups an clearly be identified by the doors that they need to have
access to.
Programming Door Groups
Enter your [USER CODE] to logon to the keypad.
In the example door group configuration door group DG010 is being edited. Modifying the
All Doors
group is not recommended.
Door group to
modify: DG001
Select the door group add/modify sub menu item located in the main menu [MENU,2,3] This will take you to the
screen asking to select a door group number to modify. The first door group number will be shown. The cursor
will be located over the first number.
DG010 Name
Warehouse Doors
The cursor will be positioned at the start of the door group name entry. Press [ENTER] key to save the name and
move to the next programming screen. Press the [DISARM] key to clear the name or to recall the current name
press the [ARM] key.
DG010 ScheduleÎ
None
To Next Page
