50 PRT-KLCD Protege Alphanumeric LCD Keypad User Manual | April 2011
10 Floor Groups
Floor groups are used to define what floors a user will be able to access and/or control when using elevators
within your facility. A floor group is assigned to an access level (see page 38) to restrict the ability for a user to
gain
entry to certain floors. The Protege system supports up to 250 floor groups.
10.1 All Floors Group
The All Floors group is a special floor group that allows access to all floors within the system. The All Floors group
is assigned to the master access level by default.
Changing the All Floors group is not recommended as it will restrict access to the floors used by the
Master Access Level.
10.2 Programming Floor Groups
Floor groups should be programmed so that they are used for a group of users, for example administration, legal
department and management where the groups can clearly be identified by the floors that they need to have
access to.
Programming Floor Groups
Enter your [USER CODE] to logon to the keypad.
In the example floor group configuration floor group FG010 is being edited. Modifying the
All Floors
group is not recommended.
Floor group to
modify: FG001
Select the floor group add/modify sub menu item located in the main menu [MENU,2,3]. This will take you to the
screen asking to select a floor group number to modify. The first floor group number will be shown. The cursor
will be located over the first number.
The cursor will be positioned at the start of the floor group name entry. To modify the name use the numerical
keys. Press [ENTER] key to save the name and move to the next programming screen. Press the [DISARM]
key to clear the name or to recall the current name press the [ARM] key.
FG010 ScheduleÎ
None
The display will show the schedule programming. A schedule defines when this floor group will be valid. A setting
of none will disable schedule verification. Use the [1] and [3] keys to scroll the records. The arrow Î on the top
line indicates it is a scroll selection entry screen.
FG010 SecondaryÎ
None
