PRT-KLCD Protege Alphanumeric LCD Keypad User Manual | April 2011 17
Display Alarm Memory On Logon
The alarm memory can be displayed when you logon, this option is programmed per user or per access level
based on the menu group assigned to the access level.
The Protege System features comprehensive event logging and full audit information. It is
recommended to review the event log for alarm events or inform the security system administrator.
2.12 Trouble Display
The Protege Security System continually performs self diagnostics of system devices and monitors trouble
conditions that can occur on your system.
System Trouble
logon to view.
If a trouble condition is present in the system and trouble display option is enabled for the LCD Keypad the
display will show the system trouble screen.
Trouble conditions are cleared automatically by the system. If required these can be programmed to
require acknowledgement. It is recommended that you inform your property manager or security
company immediately if a trouble condition occurs.
When a trouble condition occurs the Protege keypad can be programmed to generate an audible tone
every 120 seconds. The trouble tone is cancelled when the trouble condition is viewed or the condition
is returned to normal. Refer to the Disable Audible Output (see page 62) section to disable the keypad
beep tone.
Viewing System Troubles
Enter your [USER CODE] to logon to the keypad.
*Battery*
The system or a
Select the trouble view menu item located in the view menu [MENU,5,2]. This will take you to the trouble view
menu. If a trouble condition exists the first trouble will be shown.
The trouble view menu can also be accessed from the offline menu (see page 14), this option must be
enabled by your security professional.
component of it
has a battery
The trouble message will scroll to show the full details of the trouble condition and action that should be taken.
problem. Call
service tech.
