PRT-KLCD Protege Alphanumeric LCD Keypad User Manual | April 2011 55
13 Schedules
Schedules are used to perform functions based on a time period (up to 4) and days of the week. You can also
prevent a schedule from occurring based on a holiday setting. Schedules are accessed through the time menu
[MENU,6,2].
13.1 Programming Schedules
Enter your [USER CODE] to logon to the keypad.
Schedule to
modify: 010
Select the schedule menu item located in the main menu [MENU,6,2]. This will prompt you for a schedule to
modify with the first schedule that is available being shown.
SC010 Name
Outside Sign
The cursor will be positioned at the start of the schedule name entry. To modify the name use the numerical
keys. Press [ENTER] key to save the name and move to the next programming screen. Press the [DISARM] key
to clear the name or to recall the current name press the [ARM]key.
SC001 Start
P1 Time: --:--
The display will show the first period start entry. Enter the time that you want the period to start on. Press
[FORCE] to clear the entry to --:--.
SC001 End
P1 Time: --:--
The display will then move to the first period end entry. Enter the time that you want the period to end on. Press
[FORCE] to clear the entry to --:--.
SC010 P1 Days
[********]
The display will show the option entry screen for the days that period one will be active on. An option can be
toggled on and off (enabling the day) by using the numerical keys [1] to [8]. To view the options in text entry
mode press the [STAY] key.
SC010 P1 Hols
[********]
