PRT-KLCD Protege Alphanumeric LCD Keypad User Manual | April 2011 41
7 Menu Groups
Menu Groups are used to define what Menus a user or LCD keypad will be able to access and/or display. A
Menu Group is assigned to an access level (see page 38), to allow users to access the menus enabled on an
LCD Keypad.
The Protege system supports up to 250 menu groups.
7.1 Master Menu Group
The master menu group is a special menu group that allows access to all general functions with the exclusion of
the Installer menus.
The Master access level controls the ability for a master user to login to the system. It is strongly
recommended not to change the Master menu group or other records that are programmed for the
master to operate correctly.
7.2 Programming Menu Groups
Menu groups should be programmed so that they are used for groups of users, for example administration,
warehouse and management. Where the group can clearly be identified by the menus they need to access. This
will ensure that when the menu group is assigned to an access level it is easy to identify and manage.
Programming Menu Groups
Enter your [USER CODE] to logon to the keypad.
In the example menu group configuration, menu group MG010 is being edited. Modifying the master
menu group or the other default menu groups is not recommended and may prevent access to the
LCD Keypad or other system functions.
Menu group to
modify: MG001
Select the menu group add/modify sub menu item located in the main menu [MENU,2,2]. This will take you to
the screen asking to select a menu group number to modify. The first menu group number will be shown. The
cursor will be located over the first number. Pressing enter will take you to the name programming screen of the
selected menu group.
MG010 Name
Warehouse Menus
To modify the name use the numerical keys. Press [ENTER] key to save the name and move to the next
programming screen. Press the [DISARM] key to clear the name or to recall the current name press the [ARM]
key.
MG010 Schedule Î
None
