40 PRT-KLCD Protege Alphanumeric LCD Keypad User Manual | April 2011
The elevator group defines which elevators a user assigned the access level will be able to gain access. A setting
of None will prevent a user assigned the access level from being able to use elevators. Use the [1] and [3] keys to
scroll the records.
AL010 Floor GrpÎ
None
The floor group defines which floors a user assigned the access level will be able to gain access, a user must
also be assigned a valid elevator car group. A setting of None will prevent a user assigned the access level from
being able to unlock any floors. Use the [1] and [3] keys to scroll the records.
AL010 Misc
[********]
The display will show the option entry screen for the miscellaneous options. An option can be toggled on and off
by using the numerical keys [1] to [8]. To view the options in text entry mode press the [STAY] key.
(1) Activate PGM On Keypad Access
When enabled the PGM associated with the access level will be activated when a user logs in to an LCD Keypad.
The LCD keypad must also be programmed to activate an access level PGM (Installer Option).
(2) Activate PGM On Reader Access
When enabled the PGM associated with the access level will be activated when a user unlocks a door. The
reader must also be programmed to activate an access level PGM (Installer Option).
(3-8) Reserved Options
Do not alter reserved options.
AL010 Select
pgm: --000:00
The display will show the access level PGM. This is activated based on option 1 and 2 of the miscellaneous
options. This option should not be modified and should be configured by the installer.
AL010 PGM on
time: 00000 secs
The display will show the access level PGM activation time. This time is used when the PGM is activated. This
option should not be modified and should be configured by the installer.
