PRT-KLCD Protege Alphanumeric LCD Keypad User Manual | April 2011 49
The display will show the schedule programming. A schedule defines when this door group will be valid. A setting
of none will disable schedule verification. Use the [1] and [3] keys to scroll the records. The arrow Î on the top
line indicates it is a scroll selection entry screen.
DG010 SecondaryÎ
None
The display will show the secondary door group selection. A secondary door group if programmed will be used if
the assigned schedule is not valid. This allows an access level to be assigned door groups based on the time of
the day. By default this is set to None and is disabled if a schedule of None is programmed. Use the [1] and [3]
keys to scroll the records. The arrow Î on the top line indicates it is a scroll selection entry screen.
DG010 Block 01
[********]
The display will show the option entry screen for the first eight doors that belong to the door group. An option
can be toggled on and off (including a door into the group) by using the numerical keys [1] to [8]. To view the
options in text entry mode press the [STAY] key.
Depending on the number of doors that are available in the system the number of programmable
blocks of doors will be restricted.
DG010 Block XX
[********]
The display will show the next block of 8 doors that belong in the group. Pressing [ENTER] will move to the next
block of 8 doors until you return to the door group selection screen.
