PRT-KLCD Protege Alphanumeric LCD Keypad User Manual | April 2011 47
The display will show the schedule programming. A schedule defines when this area group will be valid. A setting
of none will disable schedule verification. Use the [1] and [3] keys to scroll the records. The arrow Î on the top
line indicates it is a scroll selection entry screen.
AG010 SecondaryÎ
None
The display will show the secondary area group selection. A secondary area group if programmed will be used if
the assigned schedule is not valid. This allows an access level to be assigned area groups based on the time of
the day. By default this is set to None and is disabled if a schedule of none is programmed. Use the [1] and [3]
keys to scroll the records. The arrow Î on the top line indicates it is a scroll selection entry screen.
AG010 Block 01
[********]
The display will show the option entry screen for the first eight areas that belong to the area group. An option can
be toggled on and off (including an area in to the group) by using the numerical keys [1] to [8]. To view the
options in text entry mode press the [STAY] key.
Depending on the number of areas that are available in the system the number of programmable
blocks of areas will be restricted.
AG010 Block XX
[********]
The display will show the next block of 8 areas that belong in the group. Pressing [ENTER] will move to the next
entry until you return to the area group selection screen.
