PRT-KLCD Protege Alphanumeric LCD Keypad User Manual | April 2011 53
The display will show the schedule programming. A schedule defines when this elevator group will be valid. A
setting of None will disable schedule verification. Use the [1] and [3] keys to scroll the records. The arrow Î on
the top line indicates it is a scroll selection entry screen.
EG010 SecondaryÎ
None
The display will show the secondary elevator group selection. A secondary elevator group if programmed will be
used if the assigned schedule is not valid. This allows an access level to be assigned elevator groups based on
the time of the day. By default this is set to None and is disabled if a schedule of None is programmed. Use the
[1] and [3] keys to scroll the records. The arrow Î on the top line indicates it is a scroll selection entry screen.
EG010 Block 01
[********]
The display will show the option entry screen for the first eight elevator cars that belong to the elevator group. An
option can be toggled on and off (including an elevator car into the group) by using the numerical keys [1] to [8].
To view the options in text entry mode press the [STAY] key.
Depending on the number of elevator cars that are available in the system the number of
programmable blocks of elevators will be restricted.
EG010 Block XX
[********]
The display will show the next block of 8 elevator cars that belong in the group. Pressing [ENTER] will move to
the next block of elevator cars until you return to the elevator car group selection screen.
