- The Trouble Area must be armed. Refer to the section Trouble Inputs | Areas and Input Types in the
Operator Reference Manual.
In the ArmorIP Internet Monitoring Software the Poll Time must be set to 40 seconds and the Grace Time
must be set to 20 seconds. Refer to the section Poll/Grace Time in the ArmorIP Version 3 Internet Monitoring
Application User Manual.
⦁ Central Station Signal Receiver
The maximum number of signal transmitting units connected to any transmission channel shall conform to the
manufacturer's recommendations. The ArmorIP Receiver supports up to 10000 simultaneous connections.
Refer to the section Internet Connections Requirements in the ArmorIP Receiver Installation Manual for further
details.
⦁ Number of attempts
In the event of unsuccessful communication, a digital alarm communicator transmitter shall make a minimum
of 5 and a maximum of 10 attempts. Where the maximum number of attempts to complete the sequence is
reached, an indication of the failure shall be made at the premises.
In the Protege system, the reporting service selected as Contact ID must have the number of attempts
programmed to 5 attempts. The Dialing Attempts option must be programmed. Refer to the section Contact
ID | Settings in the Operator Reference Manual.
If the PRT-4G-USB cellular modem is being used as the secondary reporting option in the installation, the
Report IP service assigned to the cellular modem must be programmed as above.
⦁ Check-In Time
DACT communication channel check-in time is not to exceed 24 hrs.
⦁ Trouble Input Service Test Report
- The Test Report Time must be programmed. Refer to the section Controllers | Configuration in the
Operator Reference Manual.
- The Generate Input Restore on Test Input option must be enabled. Refer to the section Controller |
Options in the Operator Reference Manual.
- The Test Report Time is Periodic option must be enabled. Refer to the section Controller | Options in the
Operator Reference Manual.
⦁ Ethernet Connections
All ethernet network connections shall be installed within the same room as the equipment.
⦁ External Wiring
All wiring extending outside of the enclosure must be protected by conduit.
⦁ Power Supply Mains Power Connection
If a flexible cord is used to connect to line voltage, strain relief must be provided for the cord inside the
enclosure or at the knockout.
The power supply is not intended to be mounted on the exterior of vault, safe, or stockroom.
⦁ Arming Signal
A bell or visual indicator used as an arming acknowledgment signal must be listed to a ULC security, signaling
or fire standard. If intended to be mounted outside, it must be rated for outdoor use.
⦁ Keypad Wiring
The RS-485 connection to the keypad must be wired such that the shorts and other faults on the RS-485 line
connection of the keypad will not cause the controller to malfunction.
⦁ Fire Areas
Fire areas shall be separated from burglar areas through area partitioning.
NOTE: Any available dry relay contact on the Protege controller or output expander may be used for the FACP
system, provided the selected output is programmed as the Report OK output.
PRT-CTRL-DIN | Protege GX DIN Rail Integrated System Controller | Installation Manual 58
