SIGNALTEK Operation Manual 1-15
Graphical User Interface Navigation
When turned on, SIGNALTEK will display the firmware version
number then boot up to the AutoTest tab. This section of the
manual will describe the various screens and the information
displayed in each screen.
There are four primary display screens in the SIGNALTEK
graphical user interface.
? AutoTest – Displays the tests that will be run when the Autotest
button is pressed. Also lets the user choose the cable ID that
will be used for the next test. Each time an Autotest is run the
results are automatically stored to the internal memory in the
active job file.
? Manual – Displays a listing of tests that can be run individually.
Selecting a test with the up/down arrows then pressing F1 will
run a test. Tests run from the Manual tab cannot be saved.
? Job – Displays a listing of current job files. Jobs can be added,
edited, or deleted. Selecting a job and pressing Enter will
display a list of tests stored in that job. Pressing Enter again
will display the results of individual tests.
? Setup – Displays a listing of options for the operation of
SIGNALTEK.
