142
ifm System Manual ecomatmobile BasicDisplay (CR0451) V01
CAN in the PDM360 CAN units acc. to SAE J1939
Parameters of the outputs
7763
Parameter Data type Description
REDSTOPLAMP BOOL red stop lamp
TRUE: OFF
FALSE: ON
AMBERWARNINGLAMP BOOL Amber warning lamp
TRUE: OUT
FALSE: ON
PROTECTLAMP BOOL protect lamp
TRUE: OFF
FALSE: ON
NUMBER BYTE number of the bytes received (0...8)
SPN WORD SPN number
FMI BYTE failure mode indicator
SPN_CM BOOL conversion method
preset = FALSE
OC BYTE occurrence count
RESULT BYTE feedback of the function block
(possible messages following table)
Possibly values for RESULT:
Value
dec | hex
Description
000 00 function block is not active
001 01 FB execution completed without error – data is valid
008 08 FB is active – no data was received
242 F2 Error: setting is not possible
