ifm System Manual ecomatmobile BasicDisplay (CR0451) V01
Annex Overview of the files and libraries used
12.2 Overview of the files and libraries used
General overview ...................................................................................................................... 236
What are the individual files and libraries used for? ................................................................. 238
2711
(as on 03 November 2010)
Depending on the unit and the desired function, different libraries and files are used. Some are
automatically loaded, others must be inserted or loaded by the programmer.
Installation of the files and libraries in the device:
Factory setting: the device contains only the boot loader.
► Load the operating system (*.H86 or *.RESX)
► Create the project (*.PRO) in the PC: enter the target (*.TRG)
► Additionally depending on device and target:
Define the PLC configuration (*.CFG)
> CoDeSys integrates the files belonging to the target into the project:
*.TRG, *.CFG, *.CHM, *.INI, *.LIB
► If required, add further libraries to the project (*.LIB).
Certain libraries automatically integrate further libraries into the project.
Some FBs in ifm libraries (ifm_*.LIB) e.g. are based on FBs in CoDeSys libraries (3S_*.LIB).
12.2.1 General overview
2712
File name Description and memory location ³)
ifm_CRnnnn_Vxxyyzz.CFG ¹)
ifm_CRnnnn_Vxx.CFG ²)
PLC configuration
per device only 1 device-specific file
inlcudes: IEC and symbolic addresses of the inputs and outputs, the flag bytes
as well as the memory allocation
…\CoDeSys V*\Targets\ifm\ifm_CRnnnncfg\Vxxyyzz
CAA-*.CHM
Online help
per device only 1 device-specific file
inlcudes: online help for this device
…\CoDeSys V*\Targets\ifm\Help\… (language)
ifm_CRnnnn_Vxxyyzz.H86
ifm_CRnnnn_Vxxyyzz.RESX
Operating system / runtime system
(must be loaded into the controller / monitor when used for the first time)
per device only 1 device-specific file
…\CoDeSys V*\Targets\ifm\Library\ifm_CRnnnn
ifm_Browser_CRnnnn.INI
CoDeSys browser commands
(CoDeSys needs the file for starting the project)
per device only 1 device-specific file
inlcudes: commands for the browser in CoDeSys
…\CoDeSys V*\Targets\ifm
ifm_Errors_CRnnnn.INI
CoDeSys error file
(CoDeSys needs the file for starting the project)
per device only 1 device-specific file
inlcudes: device-specific error messages from CoDeSys
…\CoDeSys V*\Targets\ifm
ifm_CRnnnn_Vxx.TRG
Target file
per device only 1 device-specific file
inlcudes: hardware description for CoDeSys, e.g.: memory, file locations
…\CoDeSys V*\Targets\ifm
ifm_*_Vxxyyzz.LIB
General libraries
per device several files are possible
…\CoDeSys V*\Targets\ifm\Library
