237
ifm System Manual ecomatmobile BasicDisplay (CR0451) V01
Annex Overview of the files and libraries used
File name Description and memory location ³)
ifm_CRnnnn_Vxxyyzz.LIB
Device-specific library
per device only 1 device-specific file
inlcudes: POUs of this device
…\CoDeSys V*\Targets\ifm\Library\ifm_CRnnnn
ifm_CRnnnn_*_Vxxyyzz.LIB
Device-specific libraries
per device several files are possible
following tables
…\CoDeSys V*\Targets\ifm\Library\ifm_CRnnnn
Legend:
*
CRnnnn
V*
Vxx
yy
zz
any signs
article number of the controller / monitor
CoDeSys version
version number of the ifm software
release number of the ifm software
patch number of the ifm software
¹) valid for CRnn32 target version up to V01, all other devices up to V04
²) valid for CRnn32 target version from V02 onwards, CR040n target version from V01 onwards, all
other devices from V05 onwards
³) memory location of the files:
System drive (C: / D:) \ program folder\ ifm electronic
NOTE
The software versions suitable for the selected target must always be used:
operating system (CRnnnn_Vxxyyzz.H86 / CRnnnn_Vxxyyzz.RESX)
PLC configuration (CRnnnn_Vxx.CFG)
device library (ifm_CRnnnn_Vxxyyzz.LIB )
and the further files ( chapter Overview of the files and libraries used (→ page 236
))
CRnnnn
Vxx: 00...99
yy: 00...99
zz: 00...99
device article number
target version number
release number
patch number
The basic file name (e.g. "CR0032") and the software version number "xx" (e.g. "02") must always have
the same value! Otherwise the device goes to the STOP mode.
The values for "yy" (release number) and "zz" (patch number) do not have to match.
IMPORTANT: the following files must also be loaded:
the internal libraries (created in IEC 1131) required for the project,
the configuration files (*.CFG)
and the target files (*.TRG).
