ifm System Manual ecomatmobile BasicDisplay (CR0451) V01
Limitations and programming notes Programming notes for CoDeSys projects
6.2.4 CoDeSys visualisation elements (CR0451)
8371
Bitmap graphics (BMP)  Power reserves of the device (→ page 62)
NOTE: Not all CoDeSys functions can be executed successfully on this device:
Visualisation element Functional safety for the PDM
Polyline o A polyline is to consist of maximum 5 anchor points; not scalable
A polyline is not to enclose any area.
Curve -- Not supported
Rectangle + No problems known
Rounded rectangle -- Not supported
Circle, ellipse + No problems known
Polygon o A polygon is to consist of maximum 10 anchor points; not scalable
Pie chart -- Not supported
Visualisation -- Not supported
Button -- Not supported
Table -- Not supported
Scroll bar -- Not supported
Trend curve -- Not supported
Alarm table -- Not supported
Scales + Create scale as BMP file
Pointer instrument + Represent pointer instrument as BMP file with a superposed CoDeSys
polygon
Bar graph + Create scale as BMP file
Represent value as a superposed CoDeSys rectangle
Histogram + Create scale as BMP file
Represent value as a superposed CoDeSys rectangle
Graphic file + Up to 256 per project possible
- BMP ¹)
- BMP RLE compressed
- TIFF ¹)
- JPEG ¹)
Graphics scaling mode -- Not supported
ActiveX element -- Not supported
Pointer diagram -- Not supported
Edit tools -- Not supported
+
o
--
can be used without problem
can be used with restrictions
cannot be used
¹) During the integration into the project the file is converted into an RLE compressed bitmap.
From the CoDeSys version 2.3.9.24 an additional dialogue opens when an image is integrated. Using
this dialogue the file is adapted to the colour palette (→ page 65
) used for the device. During the
colour conversion you can select between 'most similar colour' (deactivate [Dithering]) and 'Dithering'.
Drawing area:
 The left upper corner marks the home position (0,0) of the virtual and physical drawing area.
 Virtual drawing area = 2,560 x 1,536 pixels
(enlarges the physical drawing area)
 Elements in the virtual drawing area are not calculated.
