ifm System Manual ecomatmobile BasicDisplay (CR0451) V01
Limitations and programming notes Programming notes for CoDeSys projects
6.2.5 Texts (CR0451)
8436
 The smallest font size which is clearly visible on the device is 11 point.
 Permissible fonts:
- Arial (standard)
- Lucida Console
 Permissible font size [Pixel] and font weight:
- Arial: 11 (standard), 16, 24, 32 (all only normal)
- Lucida Console: 16, 24, 48*) (all only normal)
*) Lucida Console in the font size 48 only has the following characters:
- numbers 0 to 9
- special characters + - . : %
- space.
 Permissible effects:
- none (standard)
 The following text scripts are ignored:
- Western
- Hebrew
- Arabic
- Greek
- Turkish
- Baltic
- Central European
- Cyrillic
- Vietnamese
6.2.6 Movement of elements
7392
Image and text elements can be moved on the display in a defined manner.
Element movement Description
Rotate Rotate the element around a defined pivot point
Indicate the angle of rotation
- angle of rotation in [degree]
- positive value = rotation clockwise
- negative value = rotation anticlockwise
Shift Shifting of the element:
- horizontal
- vertical
- only within the drawing area
- max. until leaving the drawing area
Relative shifting of
- rectangle
- ellipse / circle
Each edge of the element can be shifted by a specified number of pixels via an
INT type variable:
- basic position of the 4 edges = zero
- new value shifts this edge by the specified value
Shift direction for value > 0:
- horizontal edge down
- vertical edge to the right
Shift direction for value < 0:
- horizontal edge up
- vertical edge to the left
