ifm System Manual ecomatmobile BasicDisplay (CR0451) V01
Limitations and programming notes Limits of the device
6.1.4 Limitations for visualisations (CR0451)
8319
Designation Limitation
Length of character strings < 80 characters
Length of path names not relevant
Number of visualisation pages < 15
Number of graphical objects per visualisation page < 20
Number of bitmaps per project < 256
depending on the size and the
available flash memory for the
application
Number of character sets per project Character sets are permanently
stored and cannot be changed.
Number of POUs ²) per project < 512
²) POU (Program Organization Unit) = function, function block or program block
Because of the limited memory:
- Avoid grouping of elements.
- Avoid visualisation as a master slide.
- Avoid visualisation of master background slides.
