ifm System Manual ecomatmobile BasicDisplay (CR0451) V01
CAN in the PDM360 CAN POUs to CANopen
Parameters of the outputs
7869
Parameter Data type Description
MASTERSTATE BYTE Master state = internal state of the master:
00
10
= 00
16
= master is booting up
03
10
= 03
16
= configuration of the nodes is running
05
10
= 05
16
= normal operating status of the master
255
10
= FF
16
= when PLC runs as slave
PLCNODEID BYTE PLC node ID = node ID of the controller the program is running on
Value = 0...127
10
= 0...7F
16
PLCBAUDRATE DWORD Output of the baud rate of the PLC
PLCVERSION DWORD Controller version
CANSTATE BYTE CAN state = status of CANopen network
Controller operated as master:
NODEID = 0 (controller itself):
00
10
= 00
16
= OK
128
10
= 80
16
= bus off
NODE ID ≠ 0 (node):
00
10
= 00
16
= OK
01
10
= 01
16
= guarding or heartbeat error on node
128
10
= 80
16
= bus off
Controller operated as slave:
00
10
= 00
16
= OK
01
10
= 01
16
= guarding or heartbeat error
128
10
= 80
16
= bus off
NODESTATE BYTE Node state = internal node state of a slave seen from the master's
perspective. The input NODEID identifies the node.
-1
10
= FF
16
= reset to ResetNode
01
10
= 01
16
= waiting for BOOTUP
02
10
= 02
16
= after receiving BOOTUP message
03
10
= 03
16
= not yet configured: PREPARED
04
10
= 04
16
=
after the configuration with SDOs: PRE-OPERATIONAL
05
10
= 05
16
= after starting the node: OPERATIONAL
97
10
= 61
16
= optional node
98
10
= 62
16
= configured device type is different from the one in
100016
99
10
= 63
16
= node guarding
LASTNODESTATE BYTE Last node state
Node state according to CANopen (with these values, the state is
coded from the node also in the according messages).
00
10
= 00
16
= BOOTUP
04
10
= 04
16
= PREPARED
05
10
= 05
16
= OPERATIONAL
127
10
= 7F
16
= PRE-OPERATIONAL
RESULT BYTE feedback of the function block
(possible messages  following table)
Possibly values for RESULT:
Value
dec | hex
Description
000 00 function block is not active
001 01 FB execution completed without error – data is valid
008 08 FB is active – not yet processed
242 F2 Error: setting is not possible
