67
ifm System Manual ecomatmobile BasicDisplay (CR0451) V01
Visualisations in the device Special information about bitmap graphics
Black-white image transformed with PDM
colour palette
Only 2 colours
Colour depth: 8 bits
Without dither
Black-white image transformed with PDM
colour palette
Only 2 colours
Colour depth: 8 bits
With dither
Black-white image transformed to
monochrome bitmap (bilevel format)
Only 2 colours
Colour depth: 1 bits
With dither
