ifm System Manual ecomatmobile BasicDisplay (CR0451) V01
CAN in the PDM360 CAN-FBs on layer 2 (RAW-CAN)
Parameters of the outputs
7504
Parameter Data type Description
BAUDRATE WORD currently set baud rate
DOWNLOAD_ID BYTE current download ID
BUSOFF BOOL Error CAN BUS OFF at the interface
WARNING_RX BOOL Warning threshold for receiving is exceeded at the interface
WARNING_TX BOOL Warning threshold for transmitting is exceeded at the interface
VERSION DWORD version of the CAN stack
BUSLOAD BYTE Current bus load in [%]
RESULT BYTE feedback of the function block
(possible messages following table)
Possibly values for RESULT:
Value
dec | hex
Description
000 00 function block is not active
001 01 function block execution completed without error
008 08 function block is active
009 09 CAN is not active
242 F2 Error: setting is not possible
