AUDAX TOP ErP
13
5.4 MAINTENANCE TECHNICIAN PROGRAMMING MENU
Menu Service
Menu item Description Range
Denition of zone Zone system sub-menu settings -
Dening plant Sub-menu to dene the devices connected to the system -
Device conguration Sub-menu to set the device's conguration -
ermoreg. heat. Central heating thermoregulation setting sub-menu -
ermoreg. cool Cooling thermoregulation setting sub-menu -
ermoreg. parameters Parameters thermoregulation setting sub-menu -
Integration System integration setting sub-menu -
Heat pump Heat pump operating parameters sub-menu -
Manual Manual operating parameters sub-menu -
Factory settings Default settings restore sub-menu Yes / No
Menu Service -> Denition of Zone
Menu item Description Range Default
Mode Display the operating mode
- Heat + Cool
-
Room control inter-
face
Enable operation of the supplied control panel if set on “R. Panel”.
If “TA” set, the central heating and cooling requests will be made based on the
request of an external thermostat.
Remote Pan-
el/T.A.
R.Panel
Enable Remote
Control
Enable operation of the supplied control panel.
If “No” is set, the control panel only displays the heat pump statuses.
N.B.: setting “No”, it is compulsory to enable the room thermostat (refer to the
next item), otherwise the machine will display an anomaly.
Yes / No Yes
Enable thermostat
Enable operation of a room thermostat to check the heat pump
PdC is controlled by contacts in the said P.C.B.
Yes / No No
Enable dew point Enable operation with a humidity probe in the control panel. Yes / No No
Menu Service -> Dening Plant
Menu item Description Range Default
External probe Enables operation with the external probe.
No / PdC
No
Enable DHW Operation in domestic circuit
Yes / No
No
Reduction function
Enable PdC operation frequency reduction, which is controlled by the said terminal
board.
Yes / No No
Power Power percentage in reduction mode. 50% ÷ 100% 75%
Circulator control
Enable the pump operation with speed set “Max.speeed” or the modulating mode
with tracking of the “Modulating” temperature dierential.
Max.speed/
Modulating
Modulating
Speed Min Value of minimum speed used in modulating operation. 19% ÷ 50% 50%
Speed Max Value of maximum speed used in modulating operation. 50% ÷ 100% 100%
Delta T Temperature delta to be maintained with modulating operation. 2 ÷ 20 5
N.B. PARAMETERS ONLY VALID FOR AUDAX TOP 18 - 21 ErP
N.B. PARAMETERS ONLY VALID FOR AUDAX TOP 6 - 8 - 12 - 16 ErP
