AUDAX TOP ErP

Menu Service -> Device conguration

Menu item Description Range Default

H.P. control

Setting “Yes”, the default control panel supplied manages the heat pump.

Setting “No”, the control panel does not control the heat pump and must be cou-

pled with other Immergas systems (for example, TRIO, MAGIS HERCULES, Or

System manager). If “No” is set, it displays another item “slave address”.

N.B.: if it is erroneously set to “No”, it is still possible to change the selection.

Yes / No Yes

Slave address

Address to congure according to the zone where the device is installed (e.g.: zone 1

= 41, zone 2 = 42, zone 3 = 43, etc...).

1 ÷ 247 -

Menu Service -> ermoreg. Heat

Menu item Description Range Default

Discharge Set min

Without the external probe it denes the minimum ow temperature that can be

set by the user. With the external probe present it denes the minimum ow tem-

perature corresponding to operation with maximum external temperature

20 ÷ 45 °C 30°C

Discharge Set max

Without the external probe it denes the maximum ow temperature that can be

set by the user. With the external probe present it denes the maximum ow tem-

perature corresponding to operation with minimum external temperature

35 ÷ 60 °C 50 °C

External Temp. min

With the external probe present it denes at what minimum external temperature

the system must operate at the maximum ow temperature

-25 ÷ +15 °C -5 °C

External Temp. max

With the external probe present it denes at what maximum external temperature

the system must operate at the minimum ow temperature

-5 ÷ +45 °C 20°C

Menu Service -> ermoreg. Cool

Menu item Description Range Default

Discharge Set min

Without the external probe it denes the minimum ow that can be set by the user.

With the external probe present it denes the minimum ow temperature corre-

sponding to operation with maximum external temperature

4 ÷ 20 °C 7 °C

Discharge Set max

Without the external probe it denes the maximum ow that can be set by the user.

With the external probe present it denes the maximum ow temperature corre-

sponding to operation with minimum external temperature

10 ÷ 25 °C 12 °C

External Temp. min

With the external probe present, it denes at what maximum external temperature

the system must operate at the minimum ow temperature

20 ÷ 45 °C 20°C

External Temp. max

With the external probe present, it denes at what minimum external temperature

the system must operate at the maximum ow temperature

20 ÷ 45 °C 35 °C

Menu Service -> ermoreg. Parameters

Menu item Description Range

Room probe modul.

It enables you to set operation of the control panel as modulating on/o: Set “Yes”, the

ow temperature will be varied depending on the room temperature set. Set “No”, the

ow temperature will be kept constant until the desired room temperature is reached.

N.B.: if an outdoor temperature probe is present, the ow temperature will be set

depending on the relative functioning curve

Yes / No Yes

System inertia

It establishes the system reaction speed according to the type of system present.

Example:

5 system with little heat inertia

10 system with normal dimensions with radiators

20 system with a lot of heat inertia (e.g. oor-standing system)

1 ÷ 20 10

Antifreeze enable Enables the room antifreeze function Yes / No Yes

Antifreeze set Allows to set the room temperature for activation of the anti-freeze function 0 ÷ 10 °C 5 °C
