AUDAX TOP ErP and Integrated System

41.2 SYSTEM MANAGER ELECTRICAL CONNECTIONS

AUDAX TOP ErP connection

Expansion kit 3.021547 connections

2-zone kit connections mix 3.021527 / 2 mix+ 1 direct 3.021528

Zone Remote Control connections 3.023364

Control Panel supply voltage (provided by default with AUDAX TOP ErP)

Boiler connections

Relay connections code 3.023946 for central heating electrical integration

Relay connections code 3.023945 for D.H.W. electrical integration/boiler

activation with On/Off contact

D.H.W. production diverter valve activation connection

Central heating/cooling diverter valve commutation connection with puffer.

(Zone control connections 3.021523)

Electric power supply

Solar system circular connection

Safety thermostat jumper or room temperature with no

zone expansion

Control Panel supply voltage provided by

default with AUDAX TOP ErP

Common probes/inputs

Boiler alarm inputs

Puffer probe 3.019375

D.H.W. probe 3.019375

Solar system storage tank probe 3.019375

Solar panel probe 3.019374

Set configuration pumps common flow probe/plate

heat exchanger 3.019375
