AUDAX TOP ErP and Integrated System

1 2

Dehumidication mode with neutral air

e cooling circuit works by partially condensing in water through the heat exchanger (6) and partially in air through the heat

exchanger (5); accordingly air post-heating is performed and this air is sent into the room in thermically neutral conditions.

46.2 OPERATING PRINCIPLE

1 - Air lter

2 - Pre-cooling coil

3 - Evaporator

4 - Compressor

5 - Condenser

6 - Post-cooling coil

7 - Fan

8 - rottle valve

9 - Dryer lter

10 - Shut-o valve

1 2

e humid air is taken from the room through the fan (7) and made to pass through the lter (1) and the pre-cooling water

coil (2), where the air itself is cooled and taken to a condition near to the saturation curve. It then passes through the evapo-

rating coil (3) where air is further cooled and dehumidied.
