5
Victrix Pro V2 150 EU 2 Victrix Pro V2 150 EU 3 Victrix Pro V2 150 EU 4 Victrix Pro V2 150 EU 5 Victrix Pro V2 150 EU
Nominal heat input (kW) 282.0 423.0 564.0 705.0
Flue diameter (mm) Ø 200 Ø 250
Residual head at the ends of the cascade (Pa) 18.0 40.0 70.0 110.0
‘Minimum speed’ parameter
Min Fan Speed (rpm)
1850*
‘Ignition speed’ parameter 1850
* Unchanged from single.
For any missing data referring to the individual appliance model, and in terms of all of the operations that need to be carried out on the appliance control
panel, refer to the relative instructions booklet.
2.1 ANTIHUMIDITY
In the case of cascade installations combined with the corresponding ue manifold kits with dampers, moisture may form on the electrodes, causing them to malfunc-
tion; to prevent the formation of moisture, enable this function (by setting the 'System settings/Anti-humidity settings/Anti-humidity function' parameter to 'ON').
is function activates the fan (when there is no heat demand) at the speed set in the 'Fan speed' parameter, with cycles of 5 minutes ON and 5 minutes OFF. e acti-
vation of this function is subordinate to the temperature read by the ow probe:
Activation occurs when the temperature reading is above 35°C while deactivation occurs when the temperature reading falls below 30°C.
In the case of simple cascade, by activating the function via the appropriate parameter from the Master appliance, the function is also automatically activated
on the Slave appliances.
With other forms of cascade (where there is no communication between individual appliances), the function must be activated on each individual appliance.
