2 Operation
2.1 General
The IMS cutter DRIVE is a device for performing cutting tasks for the purpose of renovation
unpressurized pipes and/or pipelines. The cutter allows to open inliner after renovation and to
remove obstacles (including roots, projecting seals, minor offsets).
Commissioning of the IMS cutter DRIVE requires provision of the cutter itself, the chassis with
cable drum, hose package and control unit, the accessories, and the required supply media.
The cutter consists of the following assemblies:
1
Cutter drive
2
Cutter motor
3
Camera
4
Chassis
5
Drum with manual locking brake
6
Hose package
7
Control unit
8
Control unit in case
9
Tablet PC
10
Accessories
11
Water equipment (optional) Manual reeling
12
Manual reeling with hand crank (optional)
13
Automatic reeling with manhole deflection and foot switch (optional)
14
Vehicle installation kit (optional)
15
Meter counting incl. data loading and keyboard (optional)
The optional vehicle installation kit has to be installed according the installation manual in the
attachment.
