2.2 Nominal width-dependent cutter drive setup
The axle extensions can be adjusted at 7 mm steps and the contact wheels at 10 mm steps.
The following table is to be understood as a recommendation. By deviation of the specified
setup variants, intermediate sizes of the pipe inside diameter can be realized.
Pipe inside
diameter
[mm]
Axle extensions
[mm]
Wheels
[mm]
Wheel bolts
[mm]
Extension
plate
Contact wheel
position
135
7
90
M8x25
-
3rd from top
150
14
90
M8x25
-
2nd from top
180
28
90
M8x50
-
Top
200
14
140
M8x40
A, Groove 1
Bottom
235
28
140
M8x50
A, Groove 1
Top
250
14+28
140
M8x70
A, Groove 2
Centre
300
14+56
140
M8x90
A, Groove 2
Top
350
14+28+56
140
M8x130
B, Groove 3
Centre
400
7+14+28+56
140
M8x130
B, Groove 5
Top
