R e c o m m e n d e d I M S P o w e r S u p p l i e s
IMS has designed a series of low cost miniature unregulated switchers
and unregulated linears which can handle extreme varying load condi-
tions. This makes them ideal for stepper motor drives and DC servo
motors as well. Each of these is available in either 120 or 240 VAC
conguration. See the IMS Catalog or web site (http://www.imshome.com)
for information on these supplies. Listed below are the power supplies
recommended for use with the IM483.
I P 4 0 4 U n r e g u l a t e d L i n e a r S u p p l y
Input Range
120 VAC Version ...................................102-132 VAC
240 VAC Version ...................................204-264 VAC
Output
No Load Output Voltage*.....................43 VDC @ 0 Amps
Continuous Output Rating*..................32 VDC @ 2 Amps
Peak Output Rating*.............................26 VDC @ 4 Amps
Option
IP404-240 ..............................................240 VAC Input
I S P 2 0 0 - 4 U n r e g u l a t e d S w i t c h i n g S u p p l y
Input Range
120 VAC Version ...................................102-132 VAC
240 VAC Version ...................................204-264 VAC
Output
No Load Output Voltage*.....................41 VDC @ 0 Amps
Continuous Output Rating*..................38 VDC @ 1.5 Amps
Peak Output Rating*.............................35 VDC @ 3 Amps
Option
ISP200H-4 .............................................240 VAC Input
* All measurements were taken at 25°C, 120 VAC, 60 Hz.
S e l e c t i n g a n O p t o S u p p l y
Table 5.2: +5VDC Power Supply Specications
snoitacificepSylppuSotpO
noitacificepS
epyTylppuSdednemmoceR
hctiwSroraeniLdetalugeR
CDedoM
egatloVelppiR
%01±
egatloVtuptuO CDV5+
tnerruCtuptuO
Am001
ETON eraspetsfidesuebyamCDV5+fossecxeniegatlovylppusotponA:
!mumixamAm51ottnerrucehttimilotnekat
