A p p e n d i x A
S t a n d a r d C o n n e c t i o n O p t i o n s
A p p e n d i x O v e r v i e w
The IM483 has multiple connection options available to the user. In gen-
eral, these options will not change the operational characteristics of the
driver. These connector options give the user multiple choices in how to
interface and mount the driver into a system. Listed below are the con-
nector options and how they may be used.
I M 4 8 3 - 3 4 P 1
The IM483-34P1 features the standard 8 pin terminal block at the connec-
tor P2 location. P1 has been replaced by a 34 pin header.
The typical use for this connector style is remote control of the micro-
step resolution select inputs. The advantages of this control method are
discussed later in this appendix.
I M 4 8 3 - 8 P 2
This connector option uses 8 - 0.045 square pins at the P2 connector
location. The P1 connector location uses 8 -0.025 square pins.
This connector style would be advantageous in a scenario where the user
desires to either solder or plug the IM483 directly into a system PCB. Dimen-
sions and PCB hole patterns are given later in this appendix.
I M 4 8 3 - 3 4 P 1 - 8 P 2
This option combines the features and potential uses of the IM483-34P1
and the IM483-8P2.
I M 4 8 3 - P L G
The IM483-PLG replaces both connectors P1 and P2 with an Altech 8
position pluggable interface. The removeable, plug-in screw terminal set
is available as an option (PLG-R).
This connector option is useful in system designs where ease of removal
is desired. For example, the IM483-PLG is pin compatible with the IM804/
5-PLG. If more power is needed the drives are easily swapped.
