n FAULT Output.
n Optically Isolated Inputs.
n Single Supply.
n Up to 10MHz Step Clock Rate.
n Short Circuit and Over Temperature Protection.
n Microstep Resolution to 51,200 Steps/Rev.
n Microstep Resolutions can be Changed “On-The-Fly” With-
out Loss of Motor Position.
n 20 kHz Chopping Rate.
n Automatically Switches Between Slow and Fast Decay for
Unmatched Performance.
n 14 Selectable Resolutions Both in Decimal and Binary.
n Adjustable Automatic Current Reduction.
n At Full Step Output.
n Optional On-board Indexer and Encoder Feedback.
n CE Certied.
T h e P r o d u c t M a n u a l
The main sections of this manual address the standard IM483 driver,
which come with 8 position screw terminals as a connection medium.
The different connector, input options and accessories are covered in
detail in the appendices.
The indexer (IM483I) and indexer/encoder (IM483IE) versions of the
IM483 are not covered in this document, as they have their own manual.
T h e P r o d u c t M a n u a l
The IM483 product manual in its electronic format may be downloaded
from the IMS website at http://www.imshome.com. This version includes
a Bookmark feature that allows the reader to link from a Bookmarked
Topic in the Table of Contents to a full description of
that feature’s attributes and functions. You can also
select a Topic directly from the Table of Contents Pages.
Topics with a Bookmark function are further identiable
because the cursor changes from a normal pointer to a
“nger” pointer when placed over the word.
